名称：高处作业吊篮用钢丝绳
用途：用于高出作业吊篮，也可用于其他类似提升机构
特点：1.柔软度好 2.滑轮磨损小 3.防锈性能好 4.疲劳次数高 5.高强度
材质：1.碳素镀锌
直径 Diameter | 直径公差 Toleranceon Dia | 公称抗拉强度 Tensile Strength/MPa | 参考重量 Approx Weight | |||||
1870 | 1960 | 2060 | 2160 | 2260 | 2360 | |||
mm | %D | 最小破断拉力 Minimum Breaking Load/KN | Kg/100m | |||||
6.0 | +3-2 | 24.2 | 25.4 | 26.7 | 28.0 | 29.3 | 30.6 | 14.8 |
7.0 | 33.0 | 34.6 | 36.3 | 38.1 | 40.0 | 41.6 | 20.1 | |
8.0 | 43.1 | 45.2 | 47.5 | 49.8 | 52.1 | 54.4 | 26.2 | |
8.3 | 46.4 | 48.6 | 51.1 | 53.6 | 56.0 | 58.5 | 28.2 | |
8.6 | 49.8 | 52.2 | 54.8 | 57.5 | 60.2 | 62.8 | 30.3 | |
9.0 | 54.5 | 57.2 | 60.1 | 63.0 | 65.9 | 68.8 | 33.2 | |
9.5 | 60.8 | 63.7 | 66.9 | 70.2 | 73.4 | 76.7 | 37.0 | |
10 | 67.3 | 70.6 | 74.2 | 77.8 | 81.4 | 85.0 | 41.0 | |
12 | 96.9 | 102 | 107 | 112 | 117 | 122 | 59.2 | |
14 | 132 | 138 | 145 | 152 | 159 | 167 | 80.6 | |
16 | 172 | 180 | 190 | 199 | 208 | 217 | 105 | |
直径 Diameter | 直径公差 Toleranceon Dia | 公称抗拉强度 Tensile Strength/MPa | 参考重量 Approx Weight | |||||
1870 | 1960 | 2060 | 2160 | 2260 | 2360 | |||
mm | %D | 最小破断拉力 Minimum Breaking Load/KN | Kg/100m | |||||
6.0 | +3-2 | 24.0 | 25.1 | 26.4 | 27.7 | 29.0 | 30.2 | 15.0 |
7.0 | 32.6 | 34.2 | 35.9 | 37.7 | 39.4 | 41.2 | 20.5 | |
8.0 | 42.6 | 44.7 | 46.9 | 49.2 | 51.5 | 53.8 | 26.8 | |
8.3 | 45.9 | 48.1 | 50.5 | 53.0 | 55.4 | 57.9 | 28.8 | |
8.6 | 49.2 | 51.6 | 54.2 | 56.9 | 59.5 | 62.1 | 31.0 | |
9.0 | 53.9 | 56.5 | 59.4 | 62.3 | 65.2 | 68.1 | 33.9 | |
9.5 | 60.1 | 63.0 | 66.2 | 69.4 | 72.6 | 75.8 | 37.7 | |
10 | 66.6 | 70.0 | 73.3 | 76.9 | 80.5 | 84.0 | 41.8 | |
12 | 95.9 | 100 | 106 | 111 | 116 | 121 | 60.2 | |
